YOKOGAWA AAP849 Pulse Input Module/ Analog Output Module for compatible PAC
(Pulse count Input, 4 to 20 mA output, 8-channel input / 8-channel output, Non-Isolated)
YOKOGAWA Analog I/O Modules (for FIO)
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAB842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Pulse Input Module / Analog Output Module for Compatible PAC
This module receives 8-channel pulse train signals, and outputs 4 to 20 mA. It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAP849 |
|
Number of I/O channels |
8-channel input /8-channel output, not-isolated |
|
I/O signal |
Input: transistor contact (Open collector) |
Output: 4 to 20 mA |
|
Input frequency |
0 to 12 kHz |
– |
|
Pulse detection edge |
Trailing edge |
– |
|
Allowable load resistance |
– |
0 to 750 Ω |
|
Circuit-open detection |
– |
Less than 0.65 mA |
|
Accuracy |
– |
±48 µA |
|
Data update period |
1 ms |
10 ms |
|
Output step response time |
– |
40 ms |
|
Temperature drift |
– |
±16 µA/10 °C |
|
Maximum current consumption |
310 mA (5 V DC), 250 mA (24 V DC) |
– |
|
Weight |
0.3 kg |
|
External connection |
Dedicated cable (KS1) |
Ordering Examples:
AAP849-S00
AAP849-S01
|
|
|
Description |
|
Model |
AAP849 |
Pulse Input Module/ Analog Output Module for compatible PAC
(Pulse count Input, 4 to 20 mA output, 8-channel input / 8-channel output, Non-Isolated) |
|
Suffix Codes |
-S |
Standard type |
|
0 |
Always 0 |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
