YOKOGAWA AAP149 Pulse Input Module PM1 compatible (16-channel, Pulse count, 0 to 6 kHz, Non-Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAB842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Pulse Input Module for compatible PM1
This module receives 16-channel pulse train signals from pulse train input signal conditioner cards, and counts the pulses.
|
Items |
Specifications |
|
Model |
AAP149 |
|
Number of input channels |
16, non-isolated |
|
Input signal |
Transistor contact (open collector) |
|
Input frequency |
0 to 6 kHz |
|
Withstanding voltage |
– |
|
Pulse detection edge |
Trailing edge |
|
Data update period |
2 ms |
|
Maximum current consumption |
400 mA (5 V DC) |
|
Weight |
0.3 kg |
|
External connection |
Dedicated cable (KS2) |
|
|
|
Description |
|
Model |
AAP149 |
Pulse Input Module PM1 compatible (16-channel, Pulse count, 0 to 6 kHz, Non-Isolated) |
|
Suffix Codes |
-S |
Standard type |
|
0 |
Always 0 |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
AAP149-S00
AAP149-S01
