YOKOGAWA AAB841 Analog I/O Module (1 to 5 V input, 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated)
YOKOGAWA Analog I/O Modules (for FIO)
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
|
|
|
Description |
|
Model |
AAB841 |
Analog I/O Module (1 to 5 V input, 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated) |
|
Suffix Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option Codes |
/K4A00 |
With KS Cable Interface Adapter [Model : ATK4A-00] |
|
/M4A00 |
With MAC2 Compatible Adapter [Model : ATM4A-00] |
|
/V4A00 |
With VM2 Compatible Adapter [Model : ATV4A-00] (*1) |
|
/A4S00 |
With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model : ACCC01] |
Ordering Examples:
AAB841-S50
AAB841-S53
AAB841-SE0
AAB841-SE3
AAB841-S50/M4A00
AAB841-S53/V4A00
AAB841-SE0/M4A00
AAB841-SE3/V4A00
AAB841-S50/K4A00
AAB841-S53/K4A00
AAB841-SE0/K4A00
AAB841-SE3/K4A00
AAB841-S50/A4S00
AAB841-S53/A4S00
AAB841-SE0/A4S00
AAB841-SE3/A4S00
AAB841-S50/A4S10
AAB841-S53/A4S10
AAB841-SE0/A4S10
AAB841-SE3/A4S10
AAB841-S50/A4D00
AAB841-S53/A4D00
AAB841-SE0/A4D00
AAB841-SE3/A4D00
AAB841-S50/CCC01
AAB841-S53/CCC01
AAB841-SE0/CCC01
AAB841-SE3/CCC01
Old Ordering Examples:
AAB841-S00
AAB841-S03
AAB841-S10
AAB841-S13
AAB841-S00/M4A00
AAB841-S03/V4A00
AAB841-S10/M4A00
AAB841-S13/V4A00
AAB841-S00/K4A00
AAB841-S03/K4A00
AAB841-S10/K4A00
AAB841-S13/K4A00
AAB841-S00/A4S00
AAB841-S03/A4S00
AAB841-S10/A4S00
AAB841-S13/A4S00
AAB841-S00/A4S10
AAB841-S03/A4S10
AAB841-S10/A4S10
AAB841-S13/A4S10
AAB841-S00/A4D00
AAB841-S03/A4D00
AAB841-S10/A4D00
AAB841-S13/A4D00
AAB841-S00/CCC01
AAB841-S03/CCC01
AAB841-S10/CCC01
AAB841-S13/CCC01
