YOKOGAWA AAV542 Analog I/O Module (4 to 20 mA input , 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Voltage Output Module (Non-Isolated)
This module outputs -10 to +10 V DC.
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAV542 |
|
Number of output channels |
16, non-isolated |
|
Output signal |
-10 to 10 V |
|
Withstanding voltage |
— |
|
Allowable load resistance |
More than 10 kΩ |
|
Accuracy |
Larger of ±0.3 %/FS and ±12 mV |
|
Data update period |
10 ms |
|
Output step response time |
40 ms |
|
Temperature drift |
Larger of ±0.1 %/10 °C and ±10 mV/10 °C |
|
Maximum current consumption |
450 mA (5 V DC) |
|
Weight |
0.2 kg |
|
External connection |
Pressure clamp terminal, KS cable, MIL connector cable |
|
|
|
Description |
|
Model |
AAV542 |
Analog Output Module (-10 to +10 V, 16-channel, Non-Isolated) |
|
Suffix Codes |
-S |
Standard Type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option Codes |
/K4A00 |
With KS Cable Interface Adapter [Model : ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model : ACCC01] |
Ordering Examples:
AAV542-S50
AAV542-S53
AAV542-SE0
AAV542-SE3
AAV542-S50/K4A00
AAV542-S53/K4A00
AAV542-SE0/K4A00
AAV542-SE3/K4A00
AAV542-S50/A4S00
AAV542-S53/A4S00
AAV542-SE0/A4S00
AAV542-SE3/A4S00
AAV542-S50/A4D10
AAV542-S53/A4D10
AAV542-SE0/A4D10
AAV542-SE3/A4D10
AAV542-S50/CCC01
AAV542-S53/CCC01
AAV542-SE0/CCC01
AAV542-SE3/CCC01
Old Ordering Examples:
AAV542-S00
AAV542-S03
AAV542-S10
AAV542-S13
AAV542-S00/K4A00
AAV542-S03/K4A00
AAV542-S10/K4A00
AAV542-S13/K4A00
AAV542-S00/A4S00
AAV542-S03/A4S00
AAV542-S10/A4S00
AAV542-S13/A4S00
AAV542-S00/A4D10
AAV542-S03/A4D10
AAV542-S10/A4D10
AAV542-S13/A4D10
AAV542-S00/CCC01
AAV542-S03/CCC01
AAV542-S10/CCC01
AAV542-S13/CCC01
