AAV141

YOKOGAWA AAV141 Analog Input Module (-10 to +10 V, 16-channel, Non-Isolated)

YOKOGAWA Analog I/O Modules (for FIO):

AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,

AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849

GENERAL

This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).

STANDARD SPECIFICATIONS

Current/Voltage Input Modules (Non-Isolated)

These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.

Items

Specifications

Model

AAI141

AAV141

AAV142

AAB141

Number of input channels



16, non-isolated

16, non-isolated

(differential input)



16, non-isolated

16, non-isolated (differential input at voltage input)



Input signal



4 to 20 mA DC

1 to 5 V DC

(allowable common mode voltage ± 1 V or less)



-10 to 10 V DC

Voltage input : 1to 5 V DC

(allowable common mode voltage

±1 V or less)

Current input : 4 to 20 mA DC

Allowable input current/voltage



27 mA



±7.5 V



±13 V

Voltage input : ±7.5 V Current input : 25 mA

Withstanding voltage



Input resistance

Power ON



400 (at 20 mA) to 1000



1 M or more



1 M or more

Voltage input : 1 MΩ or more Current input : 290 Ω (at 20 mA) to 450 Ω (at 4 mA)

Power OFF



500 k or more



340 k or more



660 k or more

Voltage input : 340 kΩ or more

Current input : 500 kΩ or more

Accuracy



±16 µA



±4 mV



±20 mV

Voltage input : ±4 mV Current input : ±16 μA

Weight

0.2 kg

0.2 kg

0.2 kg

0.3 kg



Current/Voltage I/O Modules (Non-Isolated)

Description

Model

AAV141

Analog Input Module (1 to 5 V, 16-channel, Non-Isolated)

Suffix Codes

-S

Standard type

5

With no explosion protection

E

With explosion protection

0

Basic type

3

With ISA Standard G3 option and temperature (-20 to 70 °C) option

Option Codes

/K4A00

With KS Cable Interface Adapter [Model: ATK4A-00]

/A4S00

With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]

/A4S10

With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]

/A4D00

With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]

/A4D10

With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]

/CCC01

With Connector Cover for MIL Cable [Model: ACCC01]

Ordering Examples:

AAV141-S50

AAV141-S53

AAV141-SE0

AAV141-SE3

AAV141-S50/K4A00

AAV141-S53/K4A00

AAV141-SE0/K4A00

AAV141-SE3/K4A00

AAV141-S50/A4S00

AAV141-S53/A4S00

AAV141-SE0/A4S00

AAV141-SE3/A4S00

AAV141-S50/A4D10

AAV141-S53/A4D10

AAV141-SE0/A4D10

AAV141-SE3/A4D10

AAV141-S50/CCC01

AAV141-S53/CCC01

AAV141-SE0/CCC01

AAV141-SE3/CCC01


Old
Ordering Examples:



AAV141-S00

AAV141-S03

AAV141-S10

AAV141-S13

AAV141-S00/K4A00

AAV141-S03/K4A00

AAV141-S10/K4A00

AAV141-S13/K4A00

AAV141-S00/A4S00

AAV141-S03/A4S00

AAV141-S10/A4S00

AAV141-S13/A4S00

AAV141-S00/A4D10

AAV141-S03/A4D10

AAV141-S10/A4D10

AAV141-S13/A4D10

AAV141-S00/CCC01

AAV141-S03/CCC01

AAV141-S10/CCC01

AAV141-S13/CCC01

#
