YOKOGAWA AAV141 Analog Input Module (-10 to +10 V, 16-channel, Non-Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAI141 |
AAV141 |
AAV142 |
AAB141 |
|
Number of input channels |
16, non-isolated |
16, non-isolated
(differential input) |
16, non-isolated |
16, non-isolated (differential input at voltage input) |
|
Input signal |
4 to 20 mA DC |
1 to 5 V DC
(allowable common mode voltage ± 1 V or less) |
-10 to 10 V DC |
Voltage input : 1to 5 V DC
(allowable common mode voltage
±1 V or less)
Current input : 4 to 20 mA DC |
|
Allowable input current/voltage |
27 mA |
±7.5 V |
±13 V |
Voltage input : ±7.5 V Current input : 25 mA |
|
Withstanding voltage |
— |
|
Input resistance |
Power ON |
400 Ω (at 20 mA) to 1000 |
1 MΩ or more |
1 MΩ or more |
Voltage input : 1 MΩ or more Current input : 290 Ω (at 20 mA) to 450 Ω (at 4 mA) |
|
Power OFF |
500 kΩ or more |
340 kΩ or more |
660 kΩ or more |
Voltage input : 340 kΩ or more
Current input : 500 kΩ or more |
|
Accuracy |
±16 µA |
±4 mV |
±20 mV |
Voltage input : ±4 mV Current input : ±16 μA |
|
Weight |
0.2 kg |
0.2 kg |
0.2 kg |
0.3 kg |
|
Current/Voltage I/O Modules (Non-Isolated)
|
|
|
Description |
|
Model |
AAV141 |
Analog Input Module (1 to 5 V, 16-channel, Non-Isolated) |
|
Suffix Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option Codes |
/K4A00 |
With KS Cable Interface Adapter [Model: ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAV141-S50
AAV141-S53
AAV141-SE0
AAV141-SE3
AAV141-S50/K4A00
AAV141-S53/K4A00
AAV141-SE0/K4A00
AAV141-SE3/K4A00
AAV141-S50/A4S00
AAV141-S53/A4S00
AAV141-SE0/A4S00
AAV141-SE3/A4S00
AAV141-S50/A4D10
AAV141-S53/A4D10
AAV141-SE0/A4D10
AAV141-SE3/A4D10
AAV141-S50/CCC01
AAV141-S53/CCC01
AAV141-SE0/CCC01
AAV141-SE3/CCC01
Old Ordering Examples:
AAV141-S00
AAV141-S03
AAV141-S10
AAV141-S13
AAV141-S00/K4A00
AAV141-S03/K4A00
AAV141-S10/K4A00
AAV141-S13/K4A00
AAV141-S00/A4S00
AAV141-S03/A4S00
AAV141-S10/A4S00
AAV141-S13/A4S00
AAV141-S00/A4D10
AAV141-S03/A4D10
AAV141-S10/A4D10
AAV141-S13/A4D10
AAV141-S00/CCC01
AAV141-S03/CCC01
AAV141-S10/CCC01
AAV141-S13/CCC01
