YOKOGAWA AAV544 Analog Output Module (-10 to +10 V, 16-channel, Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Voltage Output Modules (Isolated)
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAV544 |
|
Number of output channels |
16, isolated |
|
Output signal |
-10 to 10 V |
|
Withstanding voltage |
Between output and system: 1500 V AC Withstanding voltage, For 1 minute (*1) |
|
Allowable load resistance |
5 kΩ or more |
|
Accuracy |
The larger one among ±12 mV or ±0.3 %FS |
|
Data update period |
10 ms |
|
Drift due to ambient temperature change |
The larger one among ±0.1 %/10 ˚C or ±10 mV/10 ˚C |
|
Maximum current consumption |
860 mA (5 V DC) |
|
Weight |
0.2 kg |
|
External communication |
Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) |
|
|
|
Description |
|
Model |
AAV544 |
Analog Output Module (-10 to +10 V, 16-channel, Isolated) |
|
Suffix
Codes |
-S |
Standard Type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/K4A00 |
With KS Cable Interface Adapter [Model : ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model : ACCC01] |
Ordering Examples:
AAV544-S50
AAV544-S53
AAV544-SE0
AAV544-SE3
AAV544-S50/K4A00
AAV544-S53/K4A00
AAV544-SE0/K4A00
AAV544-SE3/K4A00
AAV544-H50/K4A00
AAV544-H53/K4A00
AAV544-HE0/K4A00
AAV544-HE3/K4A00
AAV544-S50/A4S00
AAV544-S53/A4S00
AAV544-SE0/A4S00
AAV544-SE3/A4S00
AAV544-H50/A4S00
AAV544-H53/A4S00
AAV544-HE0/A4S00
AAV544-HE3/A4S00
AAV544-S50/A4S10
AAV544-S53/A4S10
AAV544-SE0/A4S10
AAV544-SE3/A4S10
AAV544-S50/A4D00
AAV544-S53/A4D00
AAV544-SE0/A4D00
AAV544-SE3/A4D00
AAV544-S50/A4D10
AAV544-S53/A4D10
AAV544-SE0/A4D10
AAV544-SE3/A4D10
AAV544-H50/A4D10
AAV544-H53/A4D10
AAV544-HE0/A4D10
AAV544-HE3/A4D10
AAV544-S50/CCC01
AAV544-S53/CCC01
AAV544-SE0/CCC01
AAV544-SE3/CCC01
AAV544-H50/CCC01
AAV544-H53/CCC01
AAV544-HE0/CCC01
AAV544-HE3/CCC01
Old Ordering Examples:
AAV544-S00
AAV544-S03
AAV544-S10
AAV544-S13
AAV544-S00/K4A00
AAV544-S03/K4A00
AAV544-S10/K4A00
AAV544-S13/K4A00
AAV544-H00/K4A00
AAV544-H03/K4A00
AAV544-H10/K4A00
AAV544-H13/K4A00
AAV544-S00/A4S00
AAV544-S03/A4S00
AAV544-S10/A4S00
AAV544-S13/A4S00
AAV544-H00/A4S00
AAV544-H03/A4S00
AAV544-H10/A4S00
AAV544-H13/A4S00
AAV544-S00/A4S10
AAV544-S03/A4S10
AAV544-S10/A4S10
AAV544-S13/A4S10
AAV544-S00/A4D00
AAV544-S03/A4D00
AAV544-S10/A4D00
AAV544-S13/A4D00
AAV544-S00/A4D10
AAV544-S03/A4D10
AAV544-S10/A4D10
AAV544-S13/A4D10
AAV544-H00/A4D10
AAV544-H03/A4D10
AAV544-H10/A4D10
AAV544-H13/A4D10
AAV544-S00/CCC01
AAV544-S03/CCC01
AAV544-S10/CCC01
AAV544-S13/CCC01
AAV544-H00/CCC01
AAV544-H03/CCC01
AAV544-H10/CCC01
AAV544-H13/CCC01
