YOKOGAWA AAV144 Voltage Input Module (-10 to +10 V, 16-channel, Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Voltage Input Modules (Isolated)
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAV144 |
|
Number of input channels |
16, isolated |
|
Input signal |
1 to 5 V |
-10 to 10 V |
|
Switching input signals |
Input Signals can be set together for CH1 to CH16 |
|
Allowable input voltage |
±30 V |
|
Withstanding isolated voltage |
Between input and system: 1500 V AC Withstanding voltage, For 1 minute (*1) |
|
Input resistance |
Power ON |
1 MΩ |
|
Power OFF |
200 kΩ |
|
Accuracy |
±4 mV |
±20 mV |
|
Data update period |
10 ms |
|
Drift due to ambient temperature change |
±4 mV/10 ˚C |
±20 mV/10 ˚C |
|
Maximum current consumption |
500 mA (5 V DC) |
|
Weight |
0.2 kg |
|
External communication |
Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) |
|
|
|
Description |
|
Model |
AAV144 |
Analog Input Module (-10 to +10 V, 16-channel, Isolated) |
|
Suffix
Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/K4A00 |
With KS Cable Interface Adapter [Model: ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAV144-S50
AAV144-S53
AAV144-SE0
AAV144-SE3
AAV144-S50/K4A00
AAV144-S53/K4A00
AAV144-SE0/K4A00
AAV144-SE3/K4A00
AAV144-H50/K4A00
AAV144-H53/K4A00
AAV144-HE0/K4A00
AAV144-HE3/K4A00
AAV144-S50/A4S00
AAV144-S53/A4S00
AAV144-SE0/A4S00
AAV144-SE3/A4S00
AAV144-H50/A4S00
AAV144-H53/A4S00
AAV144-HE0/A4S00
AAV144-HE3/A4S00
AAV144-S50/A4S10
AAV144-S53/A4S10
AAV144-SE0/A4S10
AAV144-SE3/A4S10
AAV144-S50/A4D00
AAV144-S53/A4D00
AAV144-SE0/A4D00
AAV144-SE3/A4D00
AAV144-S50/A4D10
AAV144-S53/A4D10
AAV144-SE0/A4D10
AAV144-SE3/A4D10
AAV144-H50/A4D10
AAV144-H53/A4D10
AAV144-HE0/A4D10
AAV144-HE3/A4D10
AAV144-S50/CCC01
AAV144-S53/CCC01
AAV144-SE0/CCC01
AAV144-SE3/CCC01
AAV144-H50/CCC01
AAV144-H53/CCC01
AAV144-HE0/CCC01
AAV144-HE3/CCC01
Old Ordering Examples:
AAV144-S00
AAV144-S03
AAV144-S10
AAV144-S13
AAV144-S00/K4A00
AAV144-S03/K4A00
AAV144-S10/K4A00
AAV144-S13/K4A00
AAV144-H00/K4A00
AAV144-H03/K4A00
AAV144-H10/K4A00
AAV144-H13/K4A00
AAV144-S00/A4S00
AAV144-S03/A4S00
AAV144-S10/A4S00
AAV144-S13/A4S00
AAV144-H00/A4S00
AAV144-H03/A4S00
AAV144-H10/A4S00
AAV144-H13/A4S00
AAV144-S00/A4S10
AAV144-S03/A4S10
AAV144-S10/A4S10
AAV144-S13/A4S10
AAV144-S00/A4D00
AAV144-S03/A4D00
AAV144-S10/A4D00
AAV144-S13/A4D00
AAV144-S00/A4D10
AAV144-S03/A4D10
AAV144-S10/A4D10
AAV144-S13/A4D10
AAV144-H00/A4D10
AAV144-H03/A4D10
AAV144-H10/A4D10
AAV144-H13/A4D10
AAV144-S00/CCC01
AAV144-S03/CCC01
AAV144-S10/CCC01
AAV144-S13/CCC01
AAV144-H00/CCC01
AAV144-H03/CCC01
AAV144-H10/CCC01
AAV144-H13/CCC01
