YOKOGAWA AAI543 Current Output Module (4 to 20 mA, 16-channel, Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Current Output Modules (Isolated)
This module outputs 4 to 20 mA.
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAI543-0 |
AAI543-1 |
|
Number of output channels |
16, isolated, standard switch-over response in redundant configuration (*3) |
16, isolated, fast switch-over response in redundant configuration (*3) |
|
Output signal |
4 to 20 mA |
|
Withstanding voltage |
Between output and system: 1500 V AC, For 1 minute |
|
Allowable load resistance |
0 to 750 Ω |
|
Circuit-open detection |
Less than 0.65 mA |
|
Accuracy |
±48 µA |
|
Data update period |
10 ms |
|
Drift due to ambient temperature change |
±16 µA/10 ˚C |
|
Maximum current consumption |
230 mA (5 V DC), 540 mA (24 V DC) |
|
Weight |
0.4 kg |
|
External communication |
Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) |
|
HART communication |
Available |
|
|
|
Description |
|
Model |
AAI543 |
Analog Output Module (4 to 20 mA, 16-channel, Isolated) |
|
Suffix
Codes |
-S |
Standard type |
|
-H |
With digital communication (HART protocol) |
|
5 |
Standard switch-over response in redundant configuration with no explosion protection |
|
6 |
Fast switch-over response in redundant configuration with no explosion protection |
|
E
F |
Standard switch-over response in redundant configuration with explosion protection |
|
Fast switch-over response in redundant configuration with explosion protection |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/K4A00 |
With KS Cable Interface Adapter (For connecting AEA4D Terminal Board) [Model: ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block [Model: ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block [Model: ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAI543-S50
AAI543-H50
AAI543-S60
AAI543-H60
AAI543-SE0
AAI543-HE0
AAI543-SF0
AAI543-HF0
AAI543-S51
AAI543-H51
AAI543-S61
AAI543-H61
AAI543-SE1
AAI543-HE1
AAI543-SF1
AAI543-HF1
AAI543-S53
AAI543-H53
AAI543-S63
AAI543-H63
AAI543-SE3
AAI543-HE3
AAI543-SF3
AAI543-HF3
AAI543-S50/K4A00
AAI543-H50/A4S00
AAI543-S60/A4S10
AAI543-H60/A4D00
AAI543-SE0/A4D10
AAI543-HE0/CCC01
Old Ordering Examples:
AAI543-S00
AAI543-H00
AAI543-S10
AAI543-H10
AAI543-S01
AAI543-H01
AAI543-S11
AAI543-H11
AAI543-S03
AAI543-H03
AAI543-S13
AAI543-H13
AAI543-S00/K4A00
AAI543-H00/A4S00
AAI543-S10/A4S10
AAI543-H10/A4D00
