YOKOGAWA AAI143 Current Input Module (4 to 20 mA, 16-channel, Isolated)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Current Output Modules (Isolated)
This module outputs 4 to 20 mA.
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAI543-0 |
AAI543-1 |
|
Number of output channels |
16, isolated, standard switch-over response in redundant configuration (*3) |
16, isolated, fast switch-over response in redundant configuration (*3) |
|
Output signal |
4 to 20 mA |
|
Withstanding voltage |
Between output and system: 1500 V AC, For 1 minute |
|
Allowable load resistance |
0 to 750 Ω |
|
Circuit-open detection |
Less than 0.65 mA |
|
Accuracy |
±48 µA |
|
Data update period |
10 ms |
|
Drift due to ambient temperature change |
±16 µA/10 ˚C |
|
Maximum current consumption |
230 mA (5 V DC), 540 mA (24 V DC) |
|
Weight |
0.4 kg |
|
External communication |
Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) |
|
HART communication |
Available |
|
|
|
Description |
|
Model |
AAI143 |
Analog Input Module (4 to 20 mA, 16-channel, Isolated) |
|
Suffix
Codes |
-S |
Standard type |
|
-H |
With digital communication (HART protocol) |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/K4A00 |
With KS Cable Interface Adapter (For connecting AEA4D Terminal Board) [Model: ATK4A-00] |
|
/A4S00 |
With Pressure Clamp Terminal Block [Model: ATA4S-00] |
|
/A4S10 |
With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10] |
|
/A4D00 |
With Dual Pressure Clamp Terminal Block [Model: ATA4D-00] |
|
/A4D10 |
With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAI143-S50
AAI143-H50
AAI143-SE0
AAI143-HE0
AAI143-S53
AAI143-H53
AAI143-SE3
AAI143-HE3
AAI143-S50/K4A00
AAI143-H50/A4S00
AAI143-SE0/A4D10
AAI143-HE0/CCC01
AAI143-S50/A4S10
AAI143-H50/A4D10
Old Ordering Examples:
AAI143-S00
AAI143-H00
AAI143-S10
AAI143-H10
AAI143-S03
AAI143-H03
AAI143-S13
AAI143-H13
AAI143-S00/K4A00
AAI143-H00/A4S00
AAI143-S10/A4D10
AAI143-H10/CCC01
AAI143-S00/A4S10
AAI143-H00/A4D10
