YOKOGAWA AAP135 Pulse Input Module (8-channel, Pulse count, 0 to 10 kHz, Isolated channels)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Pulse Input Module (Isolated Channels)
This module receives contact ON/OFF, voltage pulse and current pulse. This is isolated between the field and the system as well as between each channel.
It can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAP135 |
|
Number of input channels |
8, isolated channels |
|
Input signal |
2-wire type: Contact ON/OFF, voltage pulse, current pulse
(possible to supply transmitter power supply)
3-wire type: Power-supply-type voltage pulse |
|
Input frequency |
0 to 10 kHz |
|
Withstanding voltage |
Between input and system: 500 V AC, For 1 minute
Between channels: 500 V AC, For 1 minute |
|
Minimum input pulse width |
40 µs |
|
Input signal level |
Contact input
Open/close levels of relay contact and transistor contact
Open: 100 kΩ or more, Close: 200 Ω or less
Contact capacity
When supplying 12 V DC: 15 V DC 15 mA or more
When supplying 24 V DC: 30 V DC 30 mA or more Voltage/current pulse input (Current input is converted to voltage.) VH (high level): 3 to 24 V DC
VL (low level): -1 to 8 V DC
VH-VL (swing value): 3 V or more
Signal source resistance: 1 kΩ or less |
|
Shunt resistance |
Can be selected from none/200/500/1000 Ω.
(Open when power is OFF and for the standby side in a dual-redundant configuration) |
|
Pull-up resistance |
68 kΩ (12 V DC or 24 V DC) |
|
Filter |
Filter for eliminating chattering can be set. |
|
Data update period |
2 ms |
|
Transmitter power supply |
Can select 24 V DC/12 V DC.
Limiter value 12 V DC ±10 %: 40 mA, 24 V DC ±10 %: 30 mA |
|
Maximum current consumption |
300 mA (5 V DC), 400 mA (24 V DC) |
|
Weight |
0.3 kg |
|
External connection |
Pressure clamp terminal, KS cable, MIL connector cable |
|
|
|
Description |
|
Model |
AAP135 |
Pulse Input Module (8-channel, Pulse count, 0 to 10 kHz, Isolated channels) |
|
Suffix
Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/13A00 |
With KS Cable Interface Adapter [Model: ATI3A-00] |
|
/K4A00 |
With KS Cable Interface Adapter [Model: ATK4A-00] |
|
/13S00 |
With Pressure Clamp Terminal Block for Pulse [Model: ATI3S-00] |
|
/13S10
/13D00 |
With Pressure Clamp Terminal Block for Pulse (surge absorber) [Model: ATI3S-10] |
|
With Dual Pressure Clamp Terminal Block for Pulse [Model: ATI3D-00] |
|
/13D10 |
With Dual Pressure Clamp Terminal Block for Pulse (surge absorber) [Model: ATI3D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAP135-S50
AAP135-SE0
AAP135-S53
AAP135-SE3
AAP135-S50/13A00
AAP135-SE0/13A00
AAP135-S50/K4A00
AAP135-SE0/K4A00
AAP135-S50/13S00
AAP135-SE0/13S00
AAP135-S50/13S10
AAP135-SE0/13S10
AAP135-S50/13D00
AAP135-SE0/13D00
AAP135-S50/13D10
AAP135-SE0/13D10
AAP135-S50/CCC01
AAP135-SE0/CCC01
Old Ordering Examples:
AAP135-S00
AAP135-S10
AAP135-S03
AAP135-S13
AAP135-S00/13A00
AAP135-S10/13A00
AAP135-S00/K4A00
AAP135-S10/K4A00
AAP135-S00/13S00
AAP135-S10/13S00
AAP135-S00/13S10
AAP135-S10/13S10
AAP135-S00/13D00
AAP135-S10/13D00
AAP135-S00/13D10
AAP135-S10/13D10
AAP135-S00/CCC01
AAP135-S10/CCC01
