YOKOGAWA AAR145 RTD/POT Input Module (16-channel, Isolated channels)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
TC Input/RTD Input Module (Isolated Channels)
These modules receive signals from mV, thermocouple (TC), RTD, and potentiometer (POT). These are isolated between the field and the system as well as between each channel.
They can be used in dual redundant configuration.
These two modules can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAT145 |
AAR145 |
|
Number of input channels |
16, isolated channels |
16, isolated channels |
|
Input signal |
TC: JIS C1602:1995 (*1), IEC584:1995 Type J, K, E, B (*2), R, S, T, N
mV: -100 to 150 mV, -20 to 80 mV |
RTD: JIS C1604:1997 (*3), IEC751:1995 Pt100
(3-wire type)
POT: Total resistance 100 Ω to 10 kΩ Span resistance: 50 % or more of total resistance |
|
Switching input signals |
TC/mV can be set individually for CH1 to CH16. |
RTD/POT can be selected individually for CH1 to
CH16. |
|
Allowable input voltage |
±5 V |
±5 V |
|
Withstanding voltage |
Between input and system: 500 V AC (for single card: 1500 V AC), For 1 minute
Between input channels: 200 V AC, For 1 minute |
|
Input resistance |
Power ON |
1 MΩ or more |
|
Power OFF |
1 MΩ or more |
|
Accuracy |
±40 µV |
RTD: 150 mΩ POT: ±0.2 %/FS |
|
Allowable total resistance of signal source plus wiring |
1000 Ω or less |
150 Ω or less (wiring resistance per wire) |
|
Effect of allowable signal source resistance (1000 Ω) |
±20 µV |
— |
|
Reference junction compensation accuracy |
±1 °C (*5) (6) |
— |
|
Measurement current |
— |
RTD: 1 mA |
|
Data update period |
1 s |
|
Burn-out |
All channels can be set together.
Setting: not available/available (UP/DOWN)
detection time: 60 s |
|
Temperature drift |
±80 µV/10 °C |
RTD: ±0.3 Ω/10 °C POT: ±0.4 %/10 °C |
|
Maximum current consumption |
350 mA (5 V DC) |
350 mA (5 V DC) |
|
Weight |
0.3 kg |
|
External connection |
Dedicated cable (KS1) |
Dedicated cable (KS8/AKB335) |
|
|
|
Description |
|
Model |
AAR145 |
RTD/POT Input Module (16-channel, Isolated channels) |
|
Suffix
Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
Ordering Examples:
AAR145-S50
AAR145-SE0
AAR145-S53
AAR145-SE3
Old Ordering Examples:
AAR145-S00
AAR145-S10
AAR145-S03
AAR145-S13
