YOKOGAWA AAI135 Analog Input Module (4 to 20 mA, 8-channel, Isolated channels)
YOKOGAWA Analog I/O Modules (for FIO):
AAI135, AAI835, AAT145, AAR145, AAP135, AAI143, AAI543, AAV144, AAV544, AAT141,
AAR181, AAI141, AAV141, AAV142, AAB141, AAV542, AAI841, AAB841, AAI842, AAP149, AAP849
GENERAL
This GS covers the hardware specifications of the Analog I/O Modules (for FIO) that can be installed in the Node Unit for ESB Bus (Local Node) (ANB10S, ANB10D), the Node Unit for ER Bus (Remote Node) (ANR10S, ANR10D) and Compact Field Control Unit (for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
STANDARD SPECIFICATIONS
Current/Voltage Input Modules (Non-Isolated)
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters. They can be used in dual redundant configuration.
Current Input Module and Current I/O Module (Isolated Channels)
The Current Input Module receives signals of 4 to 20 mA. The Current I/O Module receives and outputs signals of 4 to 20 mA. These two modules are isolated between the field and the system as well as between each channel.
These two modules can be used in dual redundant configuration.
|
Items |
Specifications |
|
Model |
AAI135 |
AAI835 |
|
Number of I/O channels |
8-channel input, isolated channels |
4-channel input/4-channel output, isolated channels |
|
I/O signal |
4 to 20 mA |
Input: 4 to 20 mA |
Output: 4 to 20 mA |
|
Allowable input current |
25 mA |
25 mA |
— |
|
Withstanding voltage |
Between input and system:
500 V AC, For 1 minute
Between input channels:
500 V AC, For 1 minute |
Between input/output and system: 500 V AC, For 1 minute
Between input/output channels: 500 V AC, For 1 minute
|
|
Input resistance |
Power ON |
290 Ω (at 20 mA) to 450 Ω (at 4 mA) |
|
Power OFF |
500 kΩ or more |
|
Allowable load resistance |
— |
— |
0 to 750 Ω (*4) |
|
Circuit-open detection |
— |
— |
Less than 0.65 mA |
|
Accuracy |
±16 µA |
Input: ±16 µA |
Output: ±48 µA |
|
Data update period |
10 ms |
|
Transmitter power supply |
15.0 V or more (at 20 mA)
29.3 V or less (at 0 mA) |
15.0 V or more (at 20 mA)
29.3 V or less (at 0 mA) |
— |
|
Temperature drift |
±16 µA/10 °C |
|
Maximum current consumption |
360 mA (5 V DC), 450 mA (24 V DC) |
360 mA (5 V DC), 450 mA (24 V DC) |
|
Weight |
0.3 kg |
|
External connection |
Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) |
|
HART communication (*6) |
Available |
Available |
MODELS AND SUFFIX CODES
|
|
|
Description |
|
Model |
AAI135 |
Analog Input Module (4 to 20 mA, 8-channel, Isolated channels) |
|
Suffix
Codes |
-S |
Standard type |
|
-H |
With digital communication (HART protocol) |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/13A00 |
With KS Cable Interface Adapter [Model: ATI3A-00] |
|
/K4A00 |
With KS Cable Interface Adapter [Model: ATK4A-00] |
|
/13S00 |
With Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3S-00] |
|
/13S10
/13D00 |
With Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3S-10] |
|
With Dual Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3D-00] |
|
/13D10 |
With Dual Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
AAI135-S50
AAI135-H50
AAI135-SE0
AAI135-HE0
AAI135-S53
AAI135-H53
AAI135-SE3
AAI135-HE3
AAI135-S50/13A00
AAI135-H50/13A00
AAI135-SE0/13A00
AAI135-HE0/13A00
AAI135-S53/13A00
AAI135-H53/13A00
AAI135-SE3/13A00
AAI135-HE3/13A00
AAI135-S50/K4A00
AAI135-H50/K4A00
AAI135-SE0/K4A00
AAI135-HE0/K4A00
AAI135-S53/K4A00
AAI135-H53/K4A00
AAI135-SE3/K4A00
AAI135-HE3/K4A00
AAI135-S50/13S00
AAI135-H50/13S00
AAI135-SE0/13S00
AAI135-HE0/13S00
AAI135-S53/13S00
AAI135-H53/13S00
AAI135-SE3/13S00
AAI135-HE3/13S00
AAI135-S50/13S10
AAI135-H50/13S10
AAI135-SE0/13S10
AAI135-HE0/13S10
AAI135-S53/13S10
AAI135-H53/13S10
AAI135-SE3/13S10
AAI135-HE3/13S10
AAI135-S50/13D00
AAI135-H50/13D00
AAI135-SE0/13D00
AAI135-HE0/13D00
AAI135-S53/13D00
AAI135-H53/13D00
AAI135-SE3/13D00
AAI135-HE3/13D00
AAI135-S50/13D10
AAI135-H50/13D10
AAI135-SE0/13D10
AAI135-HE0/13D10
AAI135-S53/13D10
AAI135-H53/13D10
AAI135-SE3/13D10
AAI135-HE3/13D10
AAI135-S50/CCC01
AAI135-H50/CCC01
AAI135-SE0/CCC01
AAI135-HE0/CCC01
AAI135-S53/CCC01
AAI135-H53/CCC01
AAI135-SE3/CCC01
AAI135-HE3/CCC01
Old Ordering Examples:
AAI135-S00
AAI135-H00
AAI135-S10
AAI135-H10
AAI135-S03
AAI135-H03
AAI135-S13
AAI135-H13
AAI135-S00/13A00
AAI135-H00/13A00
AAI135-S10/13A00
AAI135-H10/13A00
AAI135-S03/13A00
AAI135-H03/13A00
AAI135-S13/13A00
AAI135-H13/13A00
AAI135-S00/K4A00
AAI135-H00/K4A00
AAI135-S10/K4A00
AAI135-H10/K4A00
AAI135-S03/K4A00
AAI135-H03/K4A00
AAI135-S13/K4A00
AAI135-H13/K4A00
AAI135-S00/13S00
AAI135-H00/13S00
AAI135-S10/13S00
AAI135-H10/13S00
AAI135-S03/13S00
AAI135-H03/13S00
AAI135-S13/13S00
AAI135-H13/13S00
AAI135-S00/13S10
AAI135-H00/13S10
AAI135-S10/13S10
AAI135-H10/13S10
AAI135-S03/13S10
AAI135-H03/13S10
AAI135-S13/13S10
AAI135-H13/13S10
AAI135-S00/13D00
AAI135-H00/13D00
AAI135-S10/13D00
AAI135-H10/13D00
AAI135-S03/13D00
AAI135-H03/13D00
AAI135-S13/13D00
AAI135-H13/13D00
AAI135-S00/13D10
AAI135-H00/13D10
AAI135-S10/13D10
AAI135-H10/13D10
AAI135-S03/13D10
AAI135-H03/13D10
AAI135-S13/13D10
AAI135-H13/13D10
AAI135-S00/CCC01
AAI135-H00/CCC01
AAI135-S10/CCC01
AAI135-H10/CCC01
AAI135-S03/CCC01
AAI135-H03/CCC01
AAI135-S13/CCC01
AAI135-H13/CCC01
