YOKOGAWA ADV169 Digital Input Module for Compatible ST6
(64-channel, Isolated, Common Minus Side Every 16-channel)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV169 |
Digital Input Module for Compatible ST6 (64-channel, Isolated, Common Minus Side Every 16-channel) |
|
Suffix
Codes |
-P |
Standard type |
|
0 |
Always 0 |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
ADV169-P00
ADV169-P01
|
Item |
Specifications |
|
Model |
ADV869 |
ADV169 |
ADV569 |
|
Number of I/O channels |
32-channel input,
32-channel output |
64-channel input |
64-channel output |
|
Signal isolation |
Common every 16-channel |
Common every 16-channel |
Common every 16-channel |
|
Input signal |
Contact input: OFF signal 100 kΩ or more
ON signal 200 Ω or less
Minimum current value when contact is short- circuited: 1.25 mA
Voltage input: OFF signal 4.5 to 25 V DC
ON signal ±1 V DC, 200 Ω or less |
– |
|
Input contact rating |
5 V DC, 20 mA or more |
|
|
Pushbutton input function |
Not supported |
Not supported |
– |
|
Input response time |
8 ms (for status input) |
8 ms (for status input) |
– |
|
Output signal |
Transistor contact |
– |
Transistor contact |
|
Output contact rating |
Inductive load, resistive load:
30 V DC, 100 mA (*1) |
– |
Inductive load, resistive load:
30 V DC, 100 mA (*1) |
|
Output response time |
16 ms or less |
– |
16 ms or less |
|
Pulse width |
8 ms to 7200 s |
– |
8 ms to 7200 s |
|
Pulse width resolution |
8 ms, add max. 1 ms for ON/ OFF delay time |
– |
8 ms, add max. 1 ms for ON/ OFF delay time |
|
Maximum current consumption |
800 mA (5 V DC) |
800 mA (5 V DC) |
800 mA (5 V DC) |
|
Weight |
0.3 kg |
0.3 kg |
0.3 kg |
|
External connection |
Dedicated cable (KS9) |
Dedicated cable (KS9) |
Dedicated cable (KS9) |
|
Compatible card |
ST5 compatible |
ST6 compatible |
ST7 compatible |
