ADV869


YOKOGAWA ADV869 Digital I/O Module for Compatible ST5

(32-channel input/32-channel output, Isolated, Common Minus Side Every 16-channel)


YOKOGAWA
Digital I/O Modules (for FIO)

ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569


GENERAL

This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit

for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field

Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).

Description

Model

ADV869

Digital I/O Module for Compatible ST5

(32-channel input/32-channel output, Isolated, Common Minus Side Every 16-channel)

Sufx

Codes

-P

With pulse width function/time-proportional output function

0

Always 0

0

Basic type

1

With ISA Standard G3 option


Ordering Examples:

ADV869-P00

ADV869-P01

Item

Specications

Model

ADV869

ADV169

ADV569

Number of I/O channels

32-channel input,

32-channel output

64-channel input

64-channel output

Signal isolation

Common every 16-channel

Common every 16-channel

Common every 16-channel

Input signal

Contact input:  OFF signal 100 k or more

ON signal 200 or less

Minimum current value when contact is short- circuited: 1.25 mA

Voltage input:  OFF signal 4.5 to 25 V DC

ON signal ±1 V DC, 200 or less

Input contact rating

5 V DC, 20 mA or more

Pushbutton input function

Not supported

Not supported

Input response time

8 ms (for status input)

8 ms (for status input)

Output signal

Transistor contact

Transistor contact

Output contact rating

Inductive load, resistive load:

30 V DC, 100 mA (*1)

Inductive load, resistive load:

30 V DC, 100 mA (*1)

Output response time

16 ms or less

16 ms or less

Pulse width

8 ms to 7200 s

8 ms to 7200 s

Pulse width resolution

8 ms, add max. 1 ms for ON/ OFF delay time

8 ms, add max. 1 ms for ON/ OFF delay time

Maximum current consumption

800 mA (5 V DC)

800 mA (5 V DC)

800 mA (5 V DC)

Weight

0.3 kg

0.3 kg

0.3 kg

External connection

Dedicated cable (KS9)

Dedicated cable (KS9)

Dedicated cable (KS9)

Compatible card

ST5 compatible

ST6 compatible

ST7 compatible

#
