YOKOGAWA ADV559 Digital Output Module for Compatible ST4
(32-channel output, Isolated channels)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV559 |
Digital Output Module for Compatible ST4 (32-channel output, Isolated channels) |
|
Suffix
Codes |
-P |
With pulse width function/time-proportional output function |
|
0 |
Always 0 |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
ADV559-P00
ADV559-P01
Digital I/O Modules (CENTUM-ST Compatible)
The Digital I/O Modules (CENTUM-ST Compatible) receive contact or voltage status signals from the field, and/or output status signals to the field via transistor contacts.
|
Item |
Specifications |
|
Model |
ADV859 |
ADV159 |
ADV559 |
|
Number of I/O channels |
16-channel input,
16-channel output |
32-channel input |
32-channel output |
|
Signal isolation |
Isolated channels |
Isolated channels |
Isolated channels |
|
Input signal |
Contact input: OFF signal 100 kΩ or more
ON signal 200 Ω or less
Minimum current value when contact is short- circuited: 1.25 mA
Voltage input: OFF signal 4.5 to 25 V DC
ON signal ±1 V DC, 200 Ω or less |
– |
|
Input contact rating |
5 V DC, 20 mA or more |
– |
|
Pushbutton input function |
Not supported |
Supported |
– |
|
Input response time |
8 ms (for status input) |
8 ms (for status input) |
– |
|
Minimum ON detection time |
– |
20 ms (for pushbutton input) |
– |
|
Maximum ON/OFF cycle |
– |
25 Hz (for pushbutton input) |
– |
|
Output signal |
Transistor contact |
– |
Transistor contact |
|
Output contact rating |
Inductive load, resistive load:
30 V DC, 100 mA (*1) |
– |
Inductive load, resistive load:
30 V DC, 100 mA (*1) |
|
Output response time |
16 ms or less |
– |
16 ms or less |
|
Pulse width |
8 ms to 7200 s |
– |
8 ms to 7200 s |
|
Pulse width resolution |
8 ms, add max. 1ms for ON/OFF
delay time |
– |
8 ms, add max. 1ms for ON/OFF
delay time |
|
Maximum current consumption |
450 mA (5 V DC) |
330 mA (5 V DC) |
570 mA (5 V DC) |
|
Weight |
0.3 kg |
0.4 kg |
0.3 kg |
|
External connection |
Dedicated cable (KS2) |
Dedicated cable (KS2) |
Dedicated cable (KS2) |
|
Compatible card |
ST2 compatible |
ST3 compatible |
ST4 compatible |
