YOKOGAWA ADV561 Digital Output Module
(64-channel, 24 V DC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV561 |
Digital Output Module (64-channel, 24 V DC, Isolated) |
|
Suffix
Codes |
-P |
With pulse width output function/time-proportional output function |
|
5 |
Without status display; with no explosion protection |
|
E |
Without status display; with explosion protection |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
ADV561-P50
ADV561-PE0
ADV561-P51
ADV561-PE1
Old Ordering Examples:
ADV561-P00
ADV561-P10
ADV561-P01
ADV561-P11
Digital Output Modules
The Digital Output Modules output 32-channel or 64-channel transistor contact signals. The ADV551 and ADV561 can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV551 |
ADV557 |
ADV561 |
|
Number of output channels |
32 |
32 |
64 |
|
Rated applied voltage |
24 V DC |
24 V DC |
24 V DC |
|
Load voltage |
24 V DC, 50 mA |
24 V DC, 50 mA |
24 V DC, 100 mA |
|
External power supply voltage range |
20.4 to 26.4 V DC |
20.4 to 26.4 V DC |
20.4 to 26.4 V DC |
|
Output ON voltage maximum value |
2 V DC |
2 V DC |
2 V DC |
|
Leak current maximum value when output OFF |
0.1 mA |
0.1 mA |
0.1 mA |
|
Output format |
Current sink |
Current sink |
Current sink |
|
Maximum load current (*1) |
100 mA/channel, 26.4 V |
100 mA/channel, 26.4 V |
100 mA/channel, 26.4 V |
|
Withstanding voltage |
Between output signal and system: 2 kV AC, For 1 minute Between commons: 500 V AC, For 1
minute, common minus (–) side every 16-channel (*2) |
|
Functions
Status output
Pulse width output
Time-proportioning output |
ON/OFF status output function
One-shot pulse width output function
Time-proportioning ON/OFF |
ON/OFF status output function
—
— |
ON/OFF status output function
One-shot pulse width output function
Time-proportioning ON/OFF |
|
Output response time |
3 ms or less (for status output)
10 ms or less (for mixed status and pulse outputs) |
|
Pulse width |
8 ms to 7200 s |
|
Pulse width resolution |
8 ms, but ON/OFF delay of maximum 1 ms is added |
|
Maximum current consumption |
700 mA (5 V DC)
60 mA (external power supply) |
550 mA (5 V DC)
60 mA (external power supply) |
700 mA (5 V DC)
120 mA (external power supply) |
|
Weight |
0.2 kg |
0.3 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Pressure clamp terminal |
Dedicated cable (AKB337), MIL
connector cable |
