YOKOGAWA ADR541 Relay Output Module
(16-channel, 24 to 110 V DC/100 to 240 V AC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADR541 |
Relay Output Module (16-channel, 24 to 110 V DC/100 to 240 V AC, Isolated) |
|
Suffix
Codes |
-P |
With pulse width output function/time-proportional output function |
|
5 |
Without status display; with no explosion protection |
|
E |
Without status display; with explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/C4S70 |
With Pressure Clamp Terminal Block for Digital Input [Model : ATC4S-70] |
Ordering Examples:
ADR541-P50
ADR541-PE0
ADR541-P53
ADR541-PE3
ADR541-P50/C4S70
ADR541-PE0/C4S70
ADR541-P53/C4S70
ADR541-PE3/C4S70
Old Ordering Examples:
ADR541-P00
ADR541-P10
ADR541-P03
ADR541-P13
ADR541-P00/C4S70
ADR541-P10/C4S70
ADR541-P03/C4S70
ADR541-P13/C4S70
Relay Output Module
The Relay Output Module outputs the 16-channel relay contact signals.
It can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADR541 |
|
Number of output channels |
16 |
|
Rated applied voltage |
24 to 110 V DC, 100 to 240 V AC, 50/60 Hz |
|
Maximum load current (*1) |
Resistive load:
24 V DC: 2.0 A/channel, 110 V DC: 0.4 A/channel
100 V AC: 2.0 A/channel, 220 V AC: 2.0 A/channel
Inductive load:
24 V DC: 0.6 A/channel, 110 V DC: 0.1 A/channel
100 V AC: 1.0 A/channel, 220 V AC: 1.0 A/channel |
|
Withstanding voltage |
Between output signal and system: 2 kV AC, For 1 minute
Between commons: 1.35 kV AC, For 1 minute, common minus (–) side every 8-channel |
|
Functions
Status output
Pulse width output
Time-proportioning output |
ON/OFF status output function
One-shot pulse width output function
Time-proportioning ON/OFF |
|
Output response time |
12 ms or less (for status output) 20 ms or less (for mixed status and pulse outputs) |
|
Pulse width |
40 ms to 7200 s |
|
Pulse width resolution |
8 ms, but ON/OFF delay added for maximum 10 ms |
|
Maximum current consumption |
780 mA (5 V DC) |
|
Weight |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB334) |
|
Relay switching life |
100000 operations (*2) |
