YOKOGAWA ADV551 Digital Output Module
(32-channel, 24 V DC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
Digital Output Module
|
|
|
Description |
|
Model |
ADV551 |
Digital Output Module (32-channel, 24 V DC, Isolated) |
|
Suffix
Codes |
-P |
With pulse width output function/time-proportional output function |
|
5 |
Without status display; with no explosion protection |
|
6 |
With status display; with no explosion protection |
|
E
F |
Without status display; with explosion protection |
|
With status display; with explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Codes |
/D5A00 |
With KS Cable Interface Adapter for 32-channel Digital [Model : ATD5A-00] |
|
/D5S00 |
With Pressure Clamp Terminal Block for Digital Output [Model : ATD5S-00] |
|
/D5S10 |
With Pressure Clamp Terminal Block for Digital Output (surge absorber) [Model : ATD5S-10] |
|
/D5D00 |
With Dual Pressure Clamp Terminal Block for Digital Output [Model : ATD5D-00] |
|
/D5D10 |
With Dual Pressure Clamp Terminal Block for Digital Output (surge absorber) [Model : ATD5D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model : ACCC01] |
Ordering Examples:
ADV551-P50
ADV551-P60
ADV551-PE0
ADV551-PF0
ADV551-P53
ADV551-P63
ADV551-PE3
ADV551-PF3
ADV551-P50/D5A00
ADV551-P60/D5A00
ADV551-PE0/D5A00
ADV551-PF0/D5A00
ADV551-P50/D5S00
ADV551-P60/D5S00
ADV551-PE0/D5S00
ADV551-PF0/D5S00
ADV551-P50/D5S10
ADV551-P60/D5S10
ADV551-PE0/D5S10
ADV551-PF0/D5S10
ADV551-P50/D5D00
ADV551-P60/D5D00
ADV551-PE0/D5D00
ADV551-PF0/D5D00
ADV551-P50/D5D10
ADV551-P60/D5D10
ADV551-PE0/D5D10
ADV551-PF0/D5D10
ADV551-P50/CCC01
ADV551-P60/CCC01
ADV551-PE0/CCC01
ADV551-PF0/CCC01
Old Ordering Examples:
ADV551-P00
ADV551-P10
ADV551-P03
ADV551-PE3
ADV551-P00/D5A00
ADV551-P10/D5A00
ADV551-P00/D5S00
ADV551-P10/D5S00
ADV551-P00/D5S10
ADV551-P10/D5S10
ADV551-P00/D5D00
ADV551-P10/D5D00
ADV551-P00/D5D10
ADV551-P10/D5D10
ADV551-P00/CCC01
ADV551-P10/CCC01
Digital Output Modules
The Digital Output Modules output 32-channel or 64-channel transistor contact signals. The ADV551 and ADV561 can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV551 |
ADV557 |
ADV561 |
|
Number of output channels |
32 |
32 |
64 |
|
Rated applied voltage |
24 V DC |
24 V DC |
24 V DC |
|
Load voltage |
24 V DC, 50 mA |
24 V DC, 50 mA |
24 V DC, 100 mA |
|
External power supply voltage range |
20.4 to 26.4 V DC |
20.4 to 26.4 V DC |
20.4 to 26.4 V DC |
|
Output ON voltage maximum value |
2 V DC |
2 V DC |
2 V DC |
|
Leak current maximum value when output OFF |
0.1 mA |
0.1 mA |
0.1 mA |
|
Output format |
Current sink |
Current sink |
Current sink |
|
Maximum load current (*1) |
100 mA/channel, 26.4 V |
100 mA/channel, 26.4 V |
100 mA/channel, 26.4 V |
|
Withstanding voltage |
Between output signal and system: 2 kV AC, For 1 minute Between commons: 500 V AC, For 1
minute, common minus (–) side every 16-channel (*2) |
|
Functions
Status output
Pulse width output
Time-proportioning output |
ON/OFF status output function
One-shot pulse width output function
Time-proportioning ON/OFF |
ON/OFF status output function
—
— |
ON/OFF status output function
One-shot pulse width output function
Time-proportioning ON/OFF |
|
Output response time |
3 ms or less (for status output)
10 ms or less (for mixed status and pulse outputs) |
|
Pulse width |
8 ms to 7200 s |
|
Pulse width resolution |
8 ms, but ON/OFF delay of maximum 1 ms is added |
|
Maximum current consumption |
700 mA (5 V DC)
60 mA (external power supply) |
550 mA (5 V DC)
60 mA (external power supply) |
700 mA (5 V DC)
120 mA (external power supply) |
|
Weight |
0.2 kg |
0.3 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Pressure clamp terminal |
Dedicated cable (AKB337), MIL
connector cable |
