YOKOGAWA ADV161 Digital Input Module
(64-channel, 24 V DC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV161 |
Digital Input Module (64-channel, 24 V DC, Isolated) |
|
Suffix Codes |
-P |
With pushbutton input |
|
5 |
Without status display; with no explosion protection |
|
E |
Without status display; with explosion protection |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
ADV161-P50
ADV161-P51
ADV161-PE0
ADV161-PE1
Old Ordering Examples:
ADV161-P00
ADV161-P01
ADV161-P10
ADV161-P11
Digital Input Modules
The Digital Input Modules receive 32-channel or 64-channel 24 V DC ON/OFF signals. The ADV151 and ADV161 can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV151-P/ADV151-E (*1) |
ADV157 |
ADV161 |
|
Number of input channels |
32 |
32 |
64 |
|
Rated input voltage (*2) |
24 V DC (sink/source) |
24 V DC (sink/source) |
24 V DC (sink/source) |
|
Input ON voltage |
18 to 26.4 V DC |
18 to 26.4 V DC |
20 to 26.4 V DC |
|
Input OFF voltage |
5.0 V DC or less |
5.0 V DC or less |
5.0 V DC or less |
|
Input current (at rated input voltage) |
4.1 mA±20 % / channel |
4.1 mA±20 % / channel |
2.5 mA±20 % / channel |
|
Maximum allowable input voltage |
30.0 V DC |
30.0 V DC |
30.0 V DC |
|
Withstanding voltage |
Between input signal and system: 2 kV AC, For 1 minute
Between commons: 500 V AC, For 1 minute, common every 16-channel (*3) |
|
Functions
Status input
Pushbutton input |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
Function for detecting
ON/OFF status
— |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
|
Input response time |
8 ms or less (for status input) |
|
Minimum ON detection time |
20 ms (for pushbutton input) |
|
Maximum ON/OFF cycle |
25 Hz (for pushbutton input) |
|
Maximum current consumption |
500 mA (5 V DC) |
350 mA (5 V DC) |
550 mA (5 V DC) |
|
Weight |
0.3 kg |
0.4 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Pressure clamp terminal |
Dedicated cable (AKB337), MIL connector cable |
