YOKOGAWA ADV157 Digital Input Module
(32-channel, 24V DC, Pressure Clamp Terminal support only, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV157 |
Digital Input Module (32-channel, 24V DC, Pressure Clamp Terminal support only, Isolated) |
|
Suffix
Codes |
-S |
Standard type |
|
5 |
With no explosion protection |
|
E |
With explosion protection |
|
0 |
Basic type |
|
1 |
With ISA Standard G3 option |
Ordering Examples:
ADV157-S50
ADV157-S51
ADV157-SE0
ADV157-SE1
Old Ordering Examples:
ADV157-S00
ADV157-S01
ADV157-S10
ADV157-S11
Digital Input Modules
The Digital Input Modules receive 32-channel or 64-channel 24 V DC ON/OFF signals. The ADV151 and ADV161 can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV151-P/ADV151-E (*1) |
ADV157 |
ADV161 |
|
Number of input channels |
32 |
32 |
64 |
|
Rated input voltage (*2) |
24 V DC (sink/source) |
24 V DC (sink/source) |
24 V DC (sink/source) |
|
Input ON voltage |
18 to 26.4 V DC |
18 to 26.4 V DC |
20 to 26.4 V DC |
|
Input OFF voltage |
5.0 V DC or less |
5.0 V DC or less |
5.0 V DC or less |
|
Input current (at rated input voltage) |
4.1 mA±20 % / channel |
4.1 mA±20 % / channel |
2.5 mA±20 % / channel |
|
Maximum allowable input voltage |
30.0 V DC |
30.0 V DC |
30.0 V DC |
|
Withstanding voltage |
Between input signal and system: 2 kV AC, For 1 minute
Between commons: 500 V AC, For 1 minute, common every 16-channel (*3) |
|
Functions
Status input
Pushbutton input |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
Function for detecting
ON/OFF status
— |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
|
Input response time |
8 ms or less (for status input) |
|
Minimum ON detection time |
20 ms (for pushbutton input) |
|
Maximum ON/OFF cycle |
25 Hz (for pushbutton input) |
|
Maximum current consumption |
500 mA (5 V DC) |
350 mA (5 V DC) |
550 mA (5 V DC) |
|
Weight |
0.3 kg |
0.4 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Pressure clamp terminal |
Dedicated cable (AKB337), MIL connector cable |
