YOKOGAWA ADV142 Digital Input Module (16-channel, 200 V - 240 V AC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
|
|
|
Description |
|
Model |
ADV142 |
Digital Input Module (16-channel, 200 V - 240 V AC, Isolated) |
|
Suffix Codes |
-P |
With pushbutton input |
|
0 |
General-purpose type |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Code |
/C4S60 |
With Pressure Clamp Terminal Block for Digital [Model : ATC4S-60] |
Ordering Examples:
ADV142-P00
AADV142-P03
ADV142-P00/C4S60
AADV142-P03/C4S60
AC Digital Input Modules
The AC Digital Input Modules receive 16-channel 100 V AC or 220 V AC ON/OFF signals. They can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV141 |
ADV142 |
|
Number of input channels |
16 |
16 |
|
Rated input voltage (*1) |
100 to 120 V AC, 50/60 Hz |
200 to 240 V AC, 50/60 Hz |
|
Input ON voltage (peak value) |
80 V AC (113 V) to 132 V AC (187 V) |
160 V AC (226 V) to 264 V AC (373 V) |
|
Input OFF voltage (peak value) |
20 V AC (28 V) or less |
40 V AC (56 V) or less |
|
Input current (TYP) |
4.7 mA (@120 V/60 Hz) / channel |
6.2 mA (@240 V/60 Hz) / channel |
|
Input current (MAX) |
7 mA / channel |
9.3 mA / channel |
|
Withstanding voltage |
Between input signal and system: 2 kV AC, For 1 minute
Between commons: 1.35 kV AC, For 1 minute, common minus (–) side every 8-channel |
|
Functions
Status input
Pushbutton input |
Function for detecting ON/OFF status
Function for counting the pushbutton edges |
|
Input response time |
160 ms or less (for status input) |
|
Minimum ON detection time |
200 ms (for pushbutton input) |
|
Maximum ON/OFF cycle |
2.5 Hz (for pushbutton input) |
|
Maximum current consumption |
500 mA (5 V DC) |
500 mA (5 V DC) |
|
Weight |
0.3 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB332) |
Pressure clamp terminal, Dedicated cable (AKB333) |
