YOKOGAWA ADV151 Digital Input Module (32-channel, 24 V DC, Isolated)
YOKOGAWA Digital I/O Modules (for FIO)
ADV151, ADV141, ADV142, ADV157, ADV161, ADV551, ADR541, ADV557, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569
GENERAL
This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D, ANB11S, ANB11D), the Node Unit for ER Bus (ANR10S, ANR10D) and the Field
Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).
MODELS AND SUFFIX CODES
Digital Input Module
|
|
|
Description |
|
Model |
ADV151 |
Digital Input Module (32-channel, 24 V DC, Isolated) |
|
Suffix
Codes
|
-P |
With pushbutton input |
|
-E |
With SOE capture (*1) |
|
5 |
Without status display; with no explosion protection |
|
6 |
With status display; with no explosion protection |
|
E |
Without status display; with explosion protection |
|
F |
With status display; with explosion protection |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option
Code |
/D5A00 |
With KS Cable Interface Adapter for 32-channel digital [Model: ATD5A-00] |
|
/B5S00 |
With Pressure Clamp Terminal Block for Digital Input [Model: ATB5S-00] |
|
/B5S10 |
With Pressure Clamp Terminal Block for Digital Input (surge absorber) [Model: ATB5S-10] |
|
/B5D00 |
With Dual Pressure Clamp Terminal Block for Digital Input [Model: ATB5D-00] |
|
/B5D10 |
With Dual Pressure Clamp Terminal Block for Digital Input (surge absorber) [Model: ATB5D-10] |
|
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
Ordering Examples:
ADV151-P50
ADV151-P60
ADV151-E50
ADV151-E60
ADV151-PE0
ADV151-PF0
ADV151-EE0
ADV151-EF0
ADV151-P53
ADV151-P63
ADV151-E53
ADV151-E63
ADV151-PE3
ADV151-PF3
ADV151-EE3
ADV151-EF3
Old Ordering Examples:
ADV151-P00
ADV151-P10
ADV151-E00
ADV151-E10
ADV151-P03
ADV151-P13
ADV151-E03
ADV151-E13
STANDARD SPECIFICATIONS
Digital Input Modules
The Digital Input Modules receive 32-channel or 64-channel 24 V DC ON/OFF signals. The ADV151 and ADV161 can be used in dual redundant configuration.
|
Item |
Specifications |
|
Model |
ADV151-P/ADV151-E (*1) |
ADV157 |
ADV161 |
|
Number of input channels |
32 |
32 |
64 |
|
Rated input voltage (*2) |
24 V DC (sink/source) |
24 V DC (sink/source) |
24 V DC (sink/source) |
|
Input ON voltage |
18 to 26.4 V DC |
18 to 26.4 V DC |
20 to 26.4 V DC |
|
Input OFF voltage |
5.0 V DC or less |
5.0 V DC or less |
5.0 V DC or less |
|
Input current (at rated input voltage) |
4.1 mA±20 % / channel |
4.1 mA±20 % / channel |
2.5 mA±20 % / channel |
|
Maximum allowable input voltage |
30.0 V DC |
30.0 V DC |
30.0 V DC |
|
Withstanding voltage |
Between input signal and system: 2 kV AC, For 1 minute
Between commons: 500 V AC, For 1 minute, common every 16-channel (*3) |
|
Functions
Status input
Pushbutton input |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
Function for detecting
ON/OFF status
— |
Function for detecting
ON/OFF status
Function for counting the pushbutton edges |
|
Input response time |
8 ms or less (for status input) |
|
Minimum ON detection time |
20 ms (for pushbutton input) |
|
Maximum ON/OFF cycle |
25 Hz (for pushbutton input) |
|
Maximum current consumption |
500 mA (5 V DC) |
350 mA (5 V DC) |
550 mA (5 V DC) |
|
Weight |
0.3 kg |
0.4 kg |
0.3 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
Pressure clamp terminal |
Dedicated cable (AKB337), MIL connector cable |
